Dante design, commissioning and support

Dante Audio Network Design & Integration Sydney

Masters Voice Technology designs, installs and supports Dante audio networks across Sydney and NSW, connecting microphones, processors, amplifiers and rooms around the way your organisation works.

Start with an assessment of your audio sources, destinations and network infrastructure. We coordinate routing, network configuration, commissioning and handover with your AV and IT teams.

Discuss your Dante project View a school project
Design and integration

Dante integration built around your audio workflow

Plan a new network or upgrade an existing system around the required sources, destinations, audio zones and operator workflows.

Dante transports digital audio between compatible devices over an IP network. The installation still needs coordinated network design, device configuration, audio routing and commissioning.

Masters Voice Technology works with your AV and IT teams to define the scope, assess the supporting network, configure routes and document the system for handover and support.

For the technical detail, read our Dante network design guide covering routing, clocking, latency and multicast.

Network switches supporting audio distribution
The Dante signal path

How does Dante Audio Networking work?

Dante converts audio channels into IP data, sends them through the network and reconstructs them at the receiving device with precise timing.

1

Audio source

A microphone, mixer, computer or media player creates an audio signal.

2

Dante network

Audio is packetised and transported through managed network switches.

3

Audio destination

A DSP, amplifier, mixer, recorder or computer receives the channel.

The important difference: the physical network connection does not define where the audio must go. Audio routes are created in software and can be changed without moving cables.

Routing and configuration

Dante Controller makes audio routing visible

Dante Controller is Audinate’s software application for discovering, configuring and routing Dante-enabled devices.

The software presents transmit channels along one side of a routing matrix and receive channels along the other. A technician can create a subscription by selecting where the two channels meet.

  • Discover Dante-enabled devices automatically.
  • Create or remove audio subscriptions.
  • Rename devices and channels clearly.
  • Check sample rates and device latency.
  • Monitor clock synchronisation.
  • Identify packet errors and network problems.
  • Save and restore routing presets.
Example routing matrix

Sources become available across the network

Transmit channels

Lectern microphone
Wireless microphone
Media player
Mixing console

Receive channels

Audio DSP
Amplifier rack
Recording system
Overflow room

Clear device and channel naming is essential. A technically working network can still be difficult to support if its routes are poorly labelled or undocumented.

Why the industry adopted Dante

The practical benefits of Dante Audio Networking

Dante makes complex audio systems easier to expand, reconfigure, monitor and connect across large facilities.

↔

Flexible routing

Send any available audio channel to any compatible destination without physically changing the cable path.

∞

Scalable systems

Expand from a small room to a multi-building deployment by adding endpoints and network capacity as required.

✦

Digital audio quality

Keep the audio signal in the digital domain and avoid the noise, interference and degradation associated with long analogue runs.

⌁

Reduced cabling

Carry many bidirectional channels through structured Ethernet or fibre links rather than large bundles of individual audio cables.

◎

Multi-manufacturer ecosystem

Dante is integrated into thousands of products from professional AV manufacturers, providing broad equipment choice.

◉

Central monitoring

View device, routing, clock and network status from central software rather than testing each physical connection individually.

What makes Dante reliable

Dante performance depends on good network design

Dante simplifies audio routing, but the underlying network must still be designed for real-time media, precise clocking and predictable delivery.

Clock synchronisation

Dante devices synchronise their internal clocks through Precision Time Protocol. This allows audio samples to remain aligned throughout the network.

Network latency

Latency settings provide time for audio packets to reach the receiver. Settings must suit the number of switches and the network design.

Quality of service

Correct QoS configuration prioritises clocking and time-sensitive audio traffic over less critical network data.

Multicast management

IGMP configuration helps direct multicast audio only to the ports that have requested it, avoiding unnecessary network traffic.

Network capacity

Channel count, sample rate, multicast flows and other applications must be considered when calculating switch and uplink capacity.

Redundant networks

Supported devices may use primary and secondary networks to provide an alternative audio path if a switch, cable or link fails.

Dante generally performs best on properly configured Gigabit or faster managed networks. Simply connecting devices to available office-network ports does not guarantee reliable professional audio.

Standards and compatibility

What is the relationship between Dante and AES67?

Dante is a complete commercial networking platform. AES67 is an interoperability standard for transporting high-performance audio between compatible IP audio systems.

Many Dante-enabled devices can exchange multicast audio with non-Dante AES67 devices when the required features are supported and configured correctly.

Dante-to-Dante connections continue to use the Dante audio transport protocol. AES67 mode is used when interoperability with another compatible networked-audio platform is required.

AES67 capability depends on the particular device and firmware. It should never be assumed solely because a product includes a network port.

At a glance

Dante provides the complete workflow

  • Automatic device discovery
  • Name-based channel routing
  • Network clock synchronisation
  • Device configuration
  • Monitoring and diagnostics
  • Cross-manufacturer Dante connectivity

AES67 provides interoperability

AES67 defines a common method for transporting compatible high-performance audio streams between different IP audio technologies.

Enterprise Dante management

What is Dante Domain Manager?

Dante Domain Manager adds centralised management, security and cross-subnet capability for larger Dante deployments.

01

User authentication

Require authorised users to sign in before they can access or change protected Dante resources.

02

Role-based access

Give administrators, technicians and operators different permissions based on their responsibilities.

03

Domains and subnets

Organise devices into logical groups by room, building, department or site and manage Dante across multiple subnets.

04

Alerts and audit logs

Monitor system events, identify offline devices and review changes made by individual users.

Dante Domain Manager is particularly relevant to universities, government facilities, performance venues, broadcast environments and larger commercial campuses where visibility and access control matter.

Real-world applications

Where is Dante Audio Networking used?

Dante is valuable wherever multiple professional audio channels need to move reliably between devices, equipment racks, rooms or buildings.

Corporate workplaces

Connect microphones, DSPs, conferencing systems, amplifiers and divisible training rooms through the facility network.

Corporate AV solutions →

Schools and universities

Distribute paging, bell, performance and presentation audio between classrooms, halls and administration areas.

Education AV solutions →

Government facilities

Route microphones, recording feeds and reinforcement audio through council chambers, hearing rooms and operations spaces.

Government AV solutions →

Pubs, hotels and clubs

Move live entertainment, television, background music and paging audio between function rooms and venue zones.

Venue AV solutions →

Houses of worship

Connect digital consoles, stage inputs, DSPs, amplifiers, recording computers and overflow spaces.

House of worship AV →

Broadcast and live production

Transport large channel counts between studios, production consoles, intercoms, stage boxes and recording systems.

Explore AV solutions →
Project application

Dante audio across a school campus

At Leichhardt Public School, Masters Voice Technology used Dante networking as part of a modern Q-SYS PA and bell system.

Dante helped distribute digital audio between system components while reducing the limitations associated with long analogue cable paths. The completed system supports scheduled bells, announcements, paging, emergency overrides and everyday school operation.

This project demonstrates where Dante creates its greatest value: multiple audio sources, distributed destinations and a system that must remain manageable over the long term.

View the school PA project View the performing arts hall project
Leichhardt Public School PA and bell system project
System components

What equipment can connect to a Dante network?

Dante is licensed to many professional AV manufacturers, allowing devices from different brands to exchange compatible audio channels.

Microphones and receivers

Beamforming microphones, wireless microphone receivers and networked microphone interfaces can place channels directly onto Dante.

Digital signal processors

DSP platforms can receive, process, mix and transmit multiple Dante channels for conferencing and sound reinforcement.

Mixing consoles and stage boxes

Live audio systems use Dante to carry stage inputs, console outputs, recording feeds and monitor channels.

Amplifiers and loudspeakers

Dante-enabled amplifiers and powered loudspeakers can receive digital audio close to the final output destination.

Computers and software

Dante Virtual Soundcard and compatible applications can connect computers to the audio network for playback and recording.

Analogue interfaces

Dante adapters and breakout interfaces connect existing analogue equipment without requiring every device to be replaced.

Product compatibility should be checked at channel, sample-rate, firmware and feature level. Having “Dante” on two products does not remove the need for proper system engineering.

Dante Level 3 capability

Designing a Dante network that remains supportable

Masters Voice Technology designs the audio workflow and network together, helping avoid the clocking, routing, bandwidth and documentation problems that can make an unmanaged Dante system difficult to maintain.

01

Define the workflow

Identify every audio source, destination, channel count, room mode and operational requirement.

02

Engineer the network

Calculate bandwidth and configure switching, QoS, multicast, addressing, VLANs and redundancy.

03

Configure and commission

Establish device names, routes, clocking, latency, presets and failover while testing every signal path.

04

Document and support

Record routes, addresses and settings, train operators and establish ongoing monitoring and maintenance.

Discuss network design and commissioning Commercial AV services
Frequently asked questions

Dante Audio Networking FAQs

What is Dante Audio Networking?

Dante is an audio-over-IP platform developed by Audinate. It transports multiple channels of professional digital audio between compatible devices using standard Ethernet network infrastructure.

Does Dante work over a normal network?

Dante uses standard IP and Ethernet technology, but a professional system should use compatible managed switches configured for real-time audio. Bandwidth, QoS, multicast and clocking requirements must be considered before using an existing network.

Does Dante require special audio cables?

Dante normally uses structured Cat cabling or fibre network links rather than dedicated analogue multicore audio cables. Cabling must still meet the required network category, distance and installation standards.

Is Dante audio compressed?

Dante Audio is generally transported as uncompressed digital audio. The precise channel count, sample rate and bit depth depend on the capabilities of the connected products.

What is Dante Controller used for?

Dante Controller discovers Dante devices and allows technicians to create audio routes, configure devices and monitor channel, clocking, latency and network status.

What happens if the Dante network fails?

The result depends on the system design. Supported Dante devices can use separate primary and secondary networks, but true resilience also requires suitable switches, cabling, power and failure planning.

Can Dante devices from different brands work together?

Yes. Compatible Dante-enabled products from different manufacturers can exchange audio. Sample rates, channel capacity, firmware and individual product features should still be checked during design.

What is the difference between Dante and AES67?

Dante is a complete platform covering discovery, routing, configuration and transport. AES67 is an interoperability standard that allows supported networked-audio systems to exchange compatible multicast audio streams.

Can Dante connect audio between different buildings?

Yes. Dante can operate across suitably designed network infrastructure. Larger routed or multi-subnet deployments may require Dante Domain Manager and coordination with the organisation’s IT team.

Do I need a certified Dante integrator?

Certification is not legally required, but trained integrators better understand clocking, latency, multicast, QoS, redundancy and troubleshooting. This becomes increasingly important in larger or operationally critical systems.

Technology that flows

Planning a Dante audio network?

Masters Voice Technology provides Dante network design, installation, configuration and support for commercial, education, government, hospitality and performance environments across Sydney and regional New South Wales.
