BenQ Master Series 75" Interactive Whiteboard for Education

Instashare 2, EzyWrite 6, Android 11.0, ClassroomCare Technology, 40-point IR touch, Wall Mount Supplied

When it comes to teacher and student health, BenQ is always ahead of the class. All BenQ interactive displays come equipped with ClassroomCare®, our proprietary line of health-centric technologies carefully designed and tested to make active engagement in the classroom safe for everyone.

Feature Summary

• High performance Octa-core processor (A73*4+A53*4), 8GB memory, 32GB storage, Android 11 (64 bit)
• BenQ ClassroomCareTM
• Germ resistant on screen, Styus Pen, Keypad & Remote Control Certify by TUV
• Low blue light /Flicker free Certify by TUV
• IP5x dust resistance, Certify by SGS IEC 60529
• 5 in 1 Smart Type C, Display / Audio / 65W fast charging / Touch / Data
• 32W Soundbar with 8 Mic Array noise and echo cancellation
• Built-in annotation software EZWrite 6 / Google classroom/ Wireless Casting software InstaShare2 / Multi Windows
• Account management system (AMS) provides personalized workspace
• Dual LAN port can use as Hub
• Top rear USB 3.0 port for external camera

BenQ Master Series 75" Interactive WhiteBoard

BenQ Board Master

Masterfully designed

Excite and inspire your students through immersive hands-on lessons while protecting their health—all on one interactive display.

• ClassroomCare®

• Dustproof

• Device management

• 65 W USB Type-C

• 2 × 16 W speakers

• Smart 6-mic array

ClassroomCare®

Protect teachers and students

Defend against the spread of germs

Reduce surface transmission in the classroom with ClassroomCare® germ-resistant screens. The touchscreen is made with a TÜV-certified nano-ionic silver formula that is 99.9% effective against common germs.

All-around protection

Since pens are often shared, they become potential vectors of germs. The RM03 is the only interactive display that comes with germ-resistant pens for extended protection.

Enhanced eye comfort

RM03 displays come with a low blue light filter and flicker-free technology for reduced eye strain and a comfortable viewing experience. Anti-glare screens additionally ensure that display content is seen clearly from anywhere in the classroom.

• TÜV certified

• Flicker-free

• Low blue light

• Anti-glare

Teach your way

Give lessons and manage classes the way you’re used to with the BenQ Board Master. Share your laptop screen and control it from the BenQ Board or use the many built-in features. Access your files on the cloud and enjoy a wide range of dynamic teaching tools.

More than just a whiteboard

Streamline class management

Annotate anywhere

The built-in Floating Tool lets teachers write on top of any app, website, document, or image. Annotate over content displayed from any connected Windows, Mac, iOS, iPad OS, Android, or Chrome OS device.

Teach freely

Enjoy the flexibility of teaching from anywhere in the room. With InstaShare 2, you can easily share your laptop, tablet, or smartphone screen onto the BenQ Board. Control your device right from the display to navigate lesson material without having to go back and forth.

A more flexible teaching experience

Everything you need to give immersive lessons is already built in. Teach from anywhere in the classroom without external devices or additional software.

Quick access

Hear and be heard

The built-in 2 × 16 W speakers and 6-microphone array ensure the entire class can hear and be heard during lessons.

Convenient connectivity

Voice assistant

Maximize student participation

Classes have never been more fun. Whether you're teaching in person or holding a hybrid class, keep your students engaged with a wide variety of teaching tools that encourage active participation from wherever they are.

Engagement on the BenQ Board

The 4K UHD RM03 offers a smooth and intuitive writing experience that allows multiple students to interact with the BenQ Board at any time. With the EZWrite whiteboard, you can make use of fun classroom tools like Team Post for more engaging lessons.

•


  Up to 40 touch points

•


  Fine IR+

•


  Classroom tools

Engagement from their seats

Empower students to participate from their seats. With InstaShare 2, students can simultaneously cast their screens onto the BenQ Board. You can also add an element of fun by using Kahoot! to play in-class games.

Uninterrupted classes

Teach anywhere

Give lessons in any distance learning environment with the EZWrite cloud whiteboard. Interact with your students on the same whiteboard in real time from different locations.

Learn anywhere

Always be ready to learn from home or invite a remote speaker. With a slot-in PC or the InstaShare Button, the BenQ Board Master is compatible with leading video conferencing software such as Zoom, Teams, and Google Meet.

Tools for IT and admin staff

BenQ Boards make display management simple so you can focus on what matters.

Centralized device management and analytics

Easily monitor and analyze the status of all your BenQ devices on a single dashboard. Manage displays, apps, and OTA updates remotely for maximum convenience.

Effective communication across school

IP5X dust protection

Awards

The BenQ Board RM03 has been recognized as a leader in education for helping transform learning in schools across North America.

 All Specifications

Panel
Screen size 65''	Screen size 75''	Screen size 86''
Panel type IPS	Panel type IPS	Panel type IPS
Resolution UHD 3840 × 2160 pixels	Resolution UHD 3840 × 2160 pixels	Resolution UHD 3840 × 2160 pixels
Active area 1428.5 × 803.5 mm	Active area 1649.7 × 927.9 mm	Active area 1895.0 × 1096.0 mm
Aspect ratio 16:9	Aspect ratio 16:9	Aspect ratio 16:9
Brightness without glass (typical) 400 nits	Brightness without glass (typical) 450 nits	Brightness without glass (typical) 450 nits
Contrast ratio (typical) 1200:1	Contrast ratio (typical) 1200:1	Contrast ratio (typical) 1200:1
Dynamic contrast ratio 30,000:1	Dynamic contrast ratio 30,000:1	Dynamic contrast ratio 30,000:1
Color depth 10-bit	Color depth 10-bit	Color depth 10-bit
Response time 8 ms	Response time 8 ms	Response time 8 ms
Color gamut 72% NTSC	Color gamut 72% NTSC	Color gamut 72% NTSC
Operation hours 18 hours / 7 days	Operation hours 18 hours / 7 days	Operation hours 18 hours / 7 days
Orientation Landscape	Orientation Landscape	Orientation Landscape
Light life (typical) 50,000 hrs	Light life (typical) 50,000 hrs	Light life (typical) 50,000 hrs
Glass
Hardness 9H tempered	Hardness 9H tempered	Hardness 9H tempered
Germ-resistant coating Nano-ionic silver	Germ-resistant coating Nano-ionic silver	Germ-resistant coating Nano-ionic silver
Anti-glare coating Yes	Anti-glare coating Yes	Anti-glare coating Yes
Touch screen
Touch technology Infrared touch	Touch technology Infrared touch	Touch technology Infrared touch
Touch points up to 40	Touch points up to 40	Touch points up to 40
Touch response time < 10 ms	Touch response time < 10 ms	Touch response time < 10 ms
System
CPU A73 × 4	CPU A73 × 4	CPU A73 × 4
GPU G52 MC 2	GPU G52 MC 2	GPU G52 MC 2
Memory | Storage 8GB | 32 GB	Memory | Storage 8GB | 32 GB	Memory | Storage 8GB | 32 GB
OS Android 9.0	OS Android 9.0	OS Android 9.0
Connectivity
HDMI (in | out) 3 × HDMI 2.0 | 1 × HDMI 2.0	HDMI (in | out) 3 × HDMI 2.0 | 1 × HDMI 2.0	HDMI (in | out) 3 × HDMI 2.0 | 1 × HDMI 2.0
DisplayPort (in | out) 1 × 1.2 | No	DisplayPort (in | out) 1 × 1.2 | No	DisplayPort (in | out) 1 × 1.2 | No
VGA (in | out) 1 | 0	VGA (in | out) 1 | 0	VGA (in | out) 1 | 0
3.5 mm Line in (1) PC Audio × 1	3.5 mm Line in (1) PC Audio × 1	3.5 mm Line in (1) PC Audio × 1
3.5 mm Line in (2) Mic × 1	3.5 mm Line in (2) Mic × 1	3.5 mm Line in (2) Mic × 1
3.5 mm Line out Earphone × 1	3.5 mm Line out Earphone × 1	3.5 mm Line out Earphone × 1
SPDIF (in | out) 0 | 1 (optical)	SPDIF (in | out) 0 | 1 (optical)	SPDIF (in | out) 0 | 1 (optical)
USB-A 2 × 2.0 + 5 × 3.2 Gen1	USB-A 2 × 2.0 + 5 × 3.2 Gen1	USB-A 2 × 2.0 + 5 × 3.2 Gen1
USB-B (for touch) 14.9 | 14.9 | 14.9 | 14.9 mm (0.6 | 0.6 | 0.6 | 0.6 inch)	USB-B (for touch) 14.9 | 14.9 | 14.9 | 14.9 mm (0.6 | 0.6 | 0.6 | 0.6 inch)	USB-B (for touch) 14.9 | 14.9 | 14.9 | 14.9 mm (0.6 | 0.6 | 0.6 | 0.6 inch)
USB-C 1 × 3. 0 (PD 65 W)	USB-C 1 × 3. 0 (PD 65 W)	USB-C 1 × 3. 0 (PD 65 W)
Slot-in PC (OPS) 1	Slot-in PC (OPS) 1	Slot-in PC (OPS) 1
Ethernet LAN 10 / 100 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 1	Ethernet LAN 10 / 100 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2	Ethernet LAN 10 / 100 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
Built-in peripherals
Microphone 6 (Max. pickup range 8m)	Microphone 6 (Max. pickup range 8m)	Microphone 6 (Max. pickup range 8m)
Speaker 2 × 16 W	Speaker 2 × 16 W	Speaker 2 × 16 W
Wi-Fi optional	Wi-Fi optional	Wi-Fi optional
Power
Power AC 100-240V 50/60Hz	Power AC 100-240V 50/60Hz	Power AC 100-240V 50/60Hz
Maximum Power Consumption (Watt) 335 W	Maximum Power Consumption (Watt) 396 W	Maximum Power Consumption (Watt) 488 W
Standby power consumption <0.5 W	Standby power consumption <0.5 W	Standby power consumption <0.5 W
Typical power consumption 113.7 W	Typical power consumption 140.9 W	Typical power consumption 166.2 W
Physical
Dimensions (W x H x D) 1506.0 × 951.0 × 122.2 mm (59.3 × 37.4 × 4.8 inch)	Dimensions (W x H x D) 1717.0 × 1065.0 × 121.5 mm (67.6 × 41.9 × 4.8 inch)	Dimensions (W x H x D) 1962.4 × 1203.4 × 121.4 mm (77.3 × 47.38 × 4.8 inch)
Shipping dimensions (W x H x D) 1660 × 1045 × 220 mm (65.4 × 41.1 × 8.7 inch)	Shipping dimensions (W x H x D) 1900 × 1160 × 225 mm (74.8 × 45.7 × 8.9 inch)	Shipping dimensions (W x H x D) 2160 × 1340 × 250 mm (85.0 × 52.8 × 9.8 inch)
Weight (product I shipping) 41.5 kg | 57.5 kg (91.49 lbs | 126.77 lbs)	Weight (product I shipping) 53.0 kg | 72.0 kg (116.8 lbs | 158.7 lbs)	Weight (product I shipping) 68.5 kg | 89.5 kg (151 lbs | 197.3 lbs)
Mount (screws) VESA 600 × 400 mm (4 × M8 × 20L)	Mount (screws) VESA 800 × 400 mm (4 × M8 × 20L)	Mount (screws) VESA 800 × 600 mm (4 × M8 × 20L)
Pen Tray 1	Pen Tray 1	Pen Tray 1
Environment
Operating temperature 0°C ~ 40°C	Operating temperature 0°C ~ 40°C	Operating temperature 0°C ~ 40°C
Storage temperature -10°C ~ 60°C	Storage temperature -10°C ~ 60°C	Storage temperature -10°C ~ 60°C
Storage humidity 10% ~ 80% RH Non-Condensing	Storage humidity 10% ~ 80% RH Non-Condensing	Storage humidity 10% ~ 80% RH Non-Condensing
Operating humidity 10% ~ 90% RH non-condensing	Operating humidity 10% ~ 90% RH non-condensing	Operating humidity 10% ~ 90% RH non-condensing
Software
Whiteboarding EZWrite 6.0	Whiteboarding EZWrite 6.0	Whiteboarding EZWrite 6.0
Wireless screen sharing InstaShare 2	Wireless screen sharing InstaShare 2	Wireless screen sharing InstaShare 2
Account management AMS	Account management AMS	Account management AMS
Device management DMS	Device management DMS	Device management DMS
Quick access tool Floating Tool	Quick access tool Floating Tool	Quick access tool Floating Tool
Broadcast system X-Sign Broadcast	Broadcast system X-Sign Broadcast	Broadcast system X-Sign Broadcast
Accessories
Cables 1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)	Cables 1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)	Cables 1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
Wall Mount (with shipment) 1	Wall Mount (with shipment) 1	Wall Mount (with shipment) 1
Stylus 2	Stylus 2	Stylus 2
Remote control 1	Remote control 1	Remote control 1
Power cord BQP: × 7 (3 m | 9.8 ft) (EU/US/AU/TW/JP/UK/IN) ; BQE x 2 (EU/UK) ; BQA × 1 (US); BQin × 1 (IN); BQtw × 1; BQC x 1 (CN)	Power cord BQP: × 7 (3 m | 9.8 ft) (EU/US/AU/TW/JP/UK/IN) ; BQE x 2 (EU/UK) ; BQA × 1 (US); BQin × 1 (IN); BQtw × 1; BQC x 1 (CN)	Power cord BQP: × 7 (3 m | 9.8 ft) (EU/US/AU/TW/JP/UK/IN) ; BQE x 2 (EU/UK) ; BQA × 1 (US); BQin × 1 (IN); BQtw × 1; BQC x 1 (CN)
